Telelaitetila

Teleshelters Samoa and Manua

Teleshelters in two different sizes. Samoa is the bigger of two telecommunication shelters in our basic models. It´s designed to host multiple operators under one cabin. Samoa can be stretched and widened to accommodate walk around racks.

Samoa is specifically designed for operators and builders that work as main contractors on pole sites. Samoa offers safe, operationally trouble-free operation and climate-controlled environment for the equipment’s and will offer superior life span for them. Life cycle costs as whole will be greatly lowered with our solutions.

Samoa has two main outer sheet metal designs. Custom designs and and materials can be offered also. Shelters are designed and manufactured by Harri Haavikko Oy.

Telecommunication shelter briefly

Shelter for teleoperators and contractors

Well-functioning and safe shelter to maintain predictable maintenance and lifecycle costs.

Teleshelter Samoa and Manua – demanding operational environments

Patented sandwich structure enables demanding structures and deliveries to be done.

Shelter accessories and buildup

No plan or customer need is too demanding for us. We offer turn key solutions. Electric planning, instrumentation, machine installation etc. can and will be done. We will take care of your worries.

High quality end product

One stop shopping. Smooth planning and installation of all equiment at one place.

Samoa and Manua references

Technical specs of teleshelter Samoa

Dimenssions

  • Outer width 2,76m
  • Outer depth 4,26m
  • Outer hight (max, with socle) 3,06m
  • Inside hight(minimum) 2,5m
  • Surface area 10 m²
  • K-Value 0,39
  • Fire Class P3 / EI 30

Sandwich panel construction

  • Wooden frame
  • Outer surface sheet metal
  • Inner surface plywood 9 mm with laminated white surface
  • 68 mm insulation
  • Color from RR- or RAL -color maps

Accessories

Electicity, lightning, climate control, cabel ways cut throughs. Custom made installation by the specific needs.

Technical specs of teleshelter Manua

Dimenssions

  • Outer width 3,26m
  • Outer depth 3,06m
  • Outer hight (max, with socle) 3,05m
  • Inside hight(minimum) 2,5m
  • Surface area 8,4 m²
  • K-Value 0,39
  • Fire Class P3 / EI 30

Sandwich panel construction

  • Wooden frame
  • Outer surface sheet metal
  • Inner surface plywood 9 mm with laminated white surface
  • 68 mm insulation
  • Color from RR- or RAL -color maps

Accessories

Electicity, lightning, climate control, cabel ways cut throughs. Custom made installation by the specific needs.

Got interested?

Contact us and let´s figure out fit for your purpose.
